| MODEL | Unit | FCV-400 | FCV-520 |
|---|---|---|---|
| X Axis | mm | 870 | 870 |
| Y Axis | mm | 360 | 385 |
| Z Axis | mm | 390 | 450 |
| Table | T Slots | T Slots | |
| Ram Travel | mm | 550 | 560 |
| Quill Travel | mm | 127 | 127 |
| Size of T Slots | mm | 3-16 | 3-16 |
| Size (LxW) | mm | 254x1270 | 254x1370 |
| Max. Load | kg | 200 | 290 |
| Taper | R8/NT30 | R8/NT30 | |
| Speed of Spindle | rpm | 16 speed 80-4600 | 16 speed 80-4600 |
| Spindle Travel | mm | 127 | 127 |
| Max. distance between table and spindle end | mm | 0-450 | 0-450 |
| Power of motor | KW | 2.2 | 3.75 |
| Max. torque of XY servo motor | N.M. | 4 | 4 |
| Table Feed | mm/min | 5-4000 | 5-4000 |
| Lubrication | Auto | Auto | |
| Overall Height | mm | 2011 | 2252 |
| Overall Depth | mm | 2087 | 2120 |
| Overall Width | mm | 1840 | 1840 |
| Net Weight | kgs | 1400 | 1600 |
